PescoTech Inh. Sandro Pesce
PescoTech Inh. Sandro Pesce dan Köln
Bu satıcı henüz bir firma açıklaması eklemedi.
Sn. (Bay) Sandro Pesce
Merheimer Str. 444
Köln
Almanya
Benzer satıcılardan güncel teklifler
Küçük ilan
Schöneiche bei Berlin
2.236 km
Tablet presi
IMA KilianPressima 8 MX - EU - B / D
IMA KilianPressima 8 MX - EU - B / D
Çağrı
Üretim yılı: 2007, çalışma saatleri: 138 h, Koşul: yeni gibi (kullanılmış), Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: 900K707385, Tablet Press PRESSIMA – As New, In Delivery Condition
Fully functional machine with complete documentation and software.
Includes multi-tip tool set EU-D (5 × 4mm) (purchase price: €12,000, 6 months old) as well as a single-tip tool set (5mm) EU-B. Both punch sets by Ritter.
The machine is equipped with an interchangeable turret. B or D tooling can be used, each in EU or TSM standard.
Operation
• Suitable for small batch production
• Main compression force measurement with digital display on the machine panel
• Digital display of the parameters set via handwheels
• Note: no automatic control system installed
Technical Data
• Speed: 10–75 rpm
• Main compression force: 50 kN
Bedpfx Aley Hl Aqe Iodb
• Precompression force: 10 kN
• Turret diameter: Ø 180 mm
• Feeder: twin-wheel, variable speed
• Drive motor: frequency-controlled, 1.5 kW
• Power supply: 400–480 V, 50/60 Hz
• Total power consumption: 1.5 kW
• Machine housing & compression area: stainless steel
• Compression area unpainted, easily accessible, surfaces hardened nickel-plated
• Central connection for dust extraction
• Central lubrication for punches via manual pump
• Automatic lubrication pump for punches and guides
• Feeder motor integrated in the head section
Mechanics
• Handwheels for tablet thickness, main pressure, precompression, and fill depth adjustment
• Rotary valve between feed tube and feeder
• Robust precompression and main compression stations
• Scrapers on upper and lower punches
• Brake magnets on lower punches
• Standard 12 mm fill shoe
• Lower punch descends after dosing
• Lower guide rail and ejection rail easily removable
• Machine status indication on the control panel
Measuring & Analysis System
• MS2300 for recording and evaluating up to 16 channels
• Measurement/evaluation of:
o Main compression force upper
o Main compression force lower
o Precompression force upper
o Ejection force
o Scraper force
o Upper and lower punch displacement
• Signal amplifiers for main compression, precompression, ejection, and scraper force available
Equipment / Features
• Upper/lower punch shank bores with 4.8 mm keyways for guided tooling
• Segmented feeder shoe
• Hard-chromed turret
• Main force measurement including display at the operator terminal
• Accessory kit Type 8 MX:
o 4 blind dies EU-B
o 4 blind dies EU-D
o 4 plugs for EU-B/EU-D and TSM-B/TSM-D
Options
• Control system retrofit with Siemens S7-1200 and Siemens TP panel possible.
Küçük ilan
Wehr
2.400 km
Masa tipi tablet presi
MultiGelCRP1
MultiGelCRP1
Çağrı
Koşul: yeni, Üretim yılı: 2026, Fonksiyonellik: tamamen fonksiyonel, garanti süresi: 12 aylar, Single-Punch Tablet Press Model CPR1
The CPR 1 benchtop press is a single-punch machine designed for tablet production. The powder is filled into a hopper and guided through a stainless steel tube into the die cavity. The adjustable punch compresses the powder, and the finished tablet is then ejected from the machine. The machine operates with continuous motion via eccentric cams. It is equipped with a control panel featuring an integrated tablet counter. Up to 3,000 tablets can be produced per hour. The tablet press can be fitted with round, oblong, or oval dies and punches. Tool changes for punches can be performed quickly and easily. All parts in contact with powder are made of AISI 316 stainless steel.
Bjdpfeykukqex Al Iedb
Technical Specifications
Machine Dimensions CPR1: 350 x 500 x 720 mm
Net Weight CPR1: 80 kg
Electrical Connection: 1 Ph. 230 V. 50 Hz
Power Consumption: 1.20 kW
Tablet Ejection: max. 3,000 tabs/h
Tablet Size: 4 – 20 mm
Küçük ilan
Bologna
2.067 km
Silindirli kompaktör
AlexanderwerkWP 200
AlexanderwerkWP 200
Çağrı
Üretim yılı: 2011, Koşul: ikinci el, Fonksiyonellik: tamamen fonksiyonel, ALEXANDERWERK RULO KOMPAKTÖRÜ, MODEL WP 200
Makine, hammaddenin sıkıştırılması işlemini yalnızca hidrolik basınç altındaki pres silindirleri ile gerçekleştirir. Özellikle üretim alanında kullanım için tasarlanmıştır. 2011 yapımıdır.
Bodpfx Aeycw Uvjl Iodb
ÖZELLİKLER
- Rulo çapı: 200 mm
- Rulo genişliği: 75 mm
- Kontrol sistemi: Harici kontrol paneli (iki hücre)
- Combi-Vent-Feeder (CVF) ile donatılmıştır; içinde CVF Karıştırıcısı ve CVF Besleme Vidası bulunur. Hammaddenin optimize edilmiş havasızlaştırılması ve mevcutsa alt boyutlu malzemenin otomatik olarak ana ürünle karıştırılması için olanak sağlar.
ÜRETİM
- Kapasite: saate kadar 500 kg (laktoz)
- Maksimum rulo aralığı: 5 mm
- Maksimum rulo hızı: 38 dev/dak
- Maksimum presleme kuvveti: 20 kN/cm
BOYUTLAR
- Yükseklik: 2.010 mm
- Genişlik: 1.245 mm
- Derinlik: 1.700 mm
- Ağırlık: 2.450 kg
- Kumanda panosu olmadan ağırlık: 2.050 kg
- Kumanda panosu ağırlığı: 400 kg
- Kumanda panosu yüksekliği: 2.100 mm
- Kumanda panosu genişliği: 800 mm
- Kumanda panosu derinliği: 600 mm
Küçük ilan
Janville
2.853 km
Döner tablet presi
IMA KilianE150 plus
IMA KilianE150 plus
Çağrı
Koşul: ikinci el, Üretim yılı: 2003, Üretici: IMA Kilian
Model: E150 plus
Versiyon: 26-EU-B
Yıl: 2003
İstasyon sayısı: 26
Kalıp tipi: B
Zımba tipi: EU-B / IPT-B
Zımba konfigürasyonu:
- Kalıp çapı: 30,16 mm
- Kalıp yüksekliği: 22,22 mm
- Maksimum tablet çapı: 16 mm
- Maksimum dolum: 15 mm
- Maksimum ana sıkıştırma: 80 kN
- Maksimum ön sıkıştırma: 23 kN
- Üretim kapasitesi: 7.800 – 160.000 tablet/saat
Teknik dokümantasyon mevcut
Bodox R A Ulspfx Al Iedb
Ağırlık: 1.500 kg
Küçük ilan
Janville
2.853 km
Silindirli kompaktör
AlexanderwerkWP120x40V
AlexanderwerkWP120x40V
Çağrı
Koşul: ikinci el, Üretim yılı: 1999, Üretici: Alexanderwerk
Model: WP120x40V
Bsdpfxjx R A Eqj Al Isdb
Yıl: 1999
Tip: Silindirli kompaktör
Uygulama: kuru granülasyon
Malzemeler: Paslanmaz çelik
Silindir çapı – 120 mm
Silindir genişliği – 40 mm
Kapasite: 40 kg/saate kadar (laktoz)
Maksimum presleme kuvveti – 20 kN/cm
Maksimum silindir aralığı – 4 mm
Maksimum silindir hızı – 15 dev/dak
Ekipman dahil:
• Allan Bradley PLC arayüzü
• Besleme hunisi
• Döner besleme rotoru
• Helisel vida: malzemenin taşınması, ön sıkıştırılması ve beslenmesi
• Silindirli kompaktörler
• Pul kırıcı
• Ön ve ince granülatör
Küçük ilan
Janville
2.853 km
Tablet presi
FettePerfecta 1000 / P1000
FettePerfecta 1000 / P1000
Çağrı
Koşul: ikinci el, Üretim yılı: 1985, Elektrik panolu Perfecta 1000 döner tablet pres makinesi
Üretici: Fette
Model: Perfecta 1000 / P1000
Yıl: 1985
Pres istasyonu sayısı: 22
Maksimum presleme kuvveti: 80 kN
Maksimum ön presleme kuvveti: 20 kN
Maksimum tablet çapı: 25 mm
Maksimum tablet kalınlığı: 10,5 mm
Maksimum saatlik üretim kapasitesi: 72.600 tablet
Maksimum dolum yüksekliği: 22 mm
Hatve çapı: 315 mm
Kalıp plakası hızı: 15-55 devir/dakika
Punch tipi: EU 1
Kalıp çapı: 38,1 mm
Kalıp yüksekliği: 23,8 mm
Punch gövde çapı: 25,4 mm
Üst punch uzunluğu: 133,6 mm
Alt punch uzunluğu: 133,6 mm
Punch’un kalıba giriş derinliği: 2 – 6 mm
Makinenin kapladığı alan: 1030 x 1090 mm
Net ağırlık: 1.800 kg
Bsdpfxjx R Awme Al Isdb
Dokümantasyon mevcut
Küçük ilan
Janville
2.853 km
Silindirli kompaktör
GerteisGMP-Polygran Macro Pactor 250/100/3
GerteisGMP-Polygran Macro Pactor 250/100/3
Çağrı
Koşul: ikinci el, Üretim yılı: 2004, Üretici: Gerteis
Model: GMP-Polygran Macro Pactor 250/100/3
Yıl: 2004
Tip: silindir sıkıştırıcı, ilaç endüstrisi için granülasyon ünitesi.
Besleme vidası
Sıkıştırma vidası
Basınç silindirli sıkıştırma bölgesi
Yıldız rotorlu ve elek granülasyon alanı
Bdedpex R Ar Refx Al Isb
Kuvvet: 1 – 20 KN/cm
Aralık genişliği: 1,0 – 6,0 mm
Basınç silindiri hızı: 1 – 30 rpm
Silindir çapı: 250 mm
Silindir genişliği: 100 mm
Kapasite: 60 – 400 Kg/H (normal değer: 200 Kg/h)
Ekipman sökülmüş ve depolanmış.
Tam elektrik ve teknik dosya + program yedeği mevcut.
Elektrik ve güvenlik kontrol kabini mevcut değil. Bu elemanlar ayrı olarak teklif edilebilir.
Küçük ilan
Janville
2.853 km
Döner tablet presi
GEACourtoy R090
GEACourtoy R090
Çağrı
Koşul: ikinci el, Üretim yılı: 1999, GEA Courtoy R 090/18 döner tablet presi ve elektrik panosu R090XT13
İstasyon sayısı: 18
Punch tipi: EU D
Maks. presleme kuvveti: 100 kN
Bdedpfx Ajx R Amhjl Isb
Maks. ön presleme kuvveti: 10 kN
Üretim hızı: 15.900 – 79.200 tablet/saat.
Maks. tablet çapı: 25 mm
Kalıp dış çapı: 56 mm
Kalıp yüksekliği: 23,81 mm
Punch gövde çapı: 25,35 mm
Pres yüksekliği: 1955 mm
Net ağırlık: 1800 kg
Tam teknik dosya.
Besleme cihazı / Yükleme hunisi / Boşaltma oluğu / Allen Bradley kontrol sistemi.
Kompakt boyut. Ekipman mükemmel durumda ve düşük çalışma saatine sahiptir.
Küçük ilan
Yerville
2.952 km
Kompresör
FETTEP1200
FETTEP1200
Çağrı
Koşul: ikinci el, Üretim yılı: 2001, Fonksiyonellik: sınırlı işlevsellik, makine/araç numarası: 09-305, toplam ağırlık: 4.800 kg, toplam uzunluk: 1.120 mm, toplam genişlik: 1.300 mm, toplam yükseklik: 1.890 mm, FETTE tablet presinin yenilenmesi gerekiyor.
Şunlarla birlikte satılır:
- 1 taret değiştirme arabası
- 1 arızalı kontrol paneli (kontrol bölümü yenilenecek)
Ayrıca 2 taretle birlikte satılır:
- 1 20 istasyonlu taret (EU1-441 G 10)
Tablet çıkışı: min 30.000 - maks 120.000
Maksimum tablet çapı: 25 mm
Dönme hızı: 25 - 100 min1
Kalıp çapı: 38,1 mm
Kalıp yüksekliği: 23,8 mm
- 1 30 istasyonlu taret (EU 19 H 11)
Tablet çıkışı: min 45.000 - maks 216.000
Maksimum tablet çapı: 13 mm
Dönme hızı: 25 - 120 min1
Kalıp çapı: 24 mm
Kalıp yüksekliği: 22,22 mm
Elektrikli: 400 V
Bedpowpu Syefx Al Isdb
Ön sıkıştırma (kN): 50
Sıkıştırma (kN): 80
Maksimum tablet boyutu (mm): 13 / 25 mm
Küçük ilan
Yerville
2.952 km
Tablet presi
CourtoyR290F / R292F
CourtoyR290F / R292F
Çağrı
Koşul: ikinci el, Üretim yılı: 1999, Fonksiyonellik: tamamen fonksiyonel, makine/araç numarası: CBR29010, giriş voltajı: 380 V, toplam genişlik: 1.310 mm, toplam uzunluk: 1.400 mm, toplam yükseklik: 2.280 mm, kumanda kabini yüksekliği: 2.200 mm, kontrol paneli uzunluğu: 600 mm, kontrol kabini genişliği: 600 mm, toplam ağırlık: 4.500 kg, Donanım: dokümantasyon / kılavuz, COURTOY R292F Tablet Presi
İki tablet kanalı ve elektrik dolabı ile makine arasındaki kablolar eksik.
Elektrik şemaları dahil tüm belgeler mevcuttur (Fransızca).
Yıl: 1999
Seri No.: CBR29010
Zımba Tipi: D
Ağırlık (kg): 4500
Üretim Hızı/saat: 43.000 - 350.000
Sıkıştırma (kN): 100
Bsdjwpuzhjpfx Al Ijdb
Ön Sıkıştırma (kN): 10
Maksimum Tablet Boyutu (mm): 25,40
Dış Kalıp Çapı (mm): 38,10
Kalıp Yüksekliği (mm): 23,81
Zımba Çapı (mm): 25,40
Küçük ilan
Hradec Králové
1.975 km
Döner tablet presi
KilianE150 Plus
KilianE150 Plus
Çağrı
Üretim yılı: 2004, Koşul: ikinci el, Kullanılmış Kilian E 150 PLUS tek taraflı döner tablet presi. Paslanmaz çelik kapaklara sahiptir. 16 mm'ye kadar takımlama kapasitesine sahip 26 istasyon, EU-B takımlama. 20 mm'ye kadar manuel olarak ayarlanabilir dolum derinliği. 23 kN'de ön presleme ve 100 kN'ye (10 ton) kadar manuel olarak ayarlanabilir ana basınç. Maksimum kapasite saatte 162.800 tablet. Paslanmaz çelikten hız değiştirmeli besleyici. Pres, frekans değiştiricili 4kW/3ph/400V/50hz el motoruyla çalıştırılır. Yeni 2004.
Bdedpfx Alowm Ar Ao Isb
Küçük ilan
Hamburg
2.509 km
Tablet presi
AMTECTAB R77 D
AMTECTAB R77 D
Çağrı
Üretim yılı: 2025, Koşul: yeni, Tek katlı tabletlerin tabletlenmesi için döner tablet presi. Kolay alet değişimi, hızlı temizlik, sessiz çalışma. Toz ayırıcı, tablet toz toplayıcı ve vakum konveyörü dahil. - Özellikler: Pres aleti: D; Pul istasyonu sayısı: 15; Bekleme modunda maksimum makine çevrim hızı: 77 çevrim/dakika (yaklaşık 69.000 tablet/saat'e karşılık gelir); maks. tablet çapı: 25 mm; maksimum doldurma derinliği: 20 mm; maksimum baskı öncesi kuvvet: 12 kN; maks. ana presleme kuvveti: 100 kN; Ürüne temas eden parçalar paslanmaz çelik SUS 316L, gövde ise paslanmaz çelik 304'ten imal edilmiştir; Güç tüketimi: 5,5 kW; Makine ölçüleri: 660×690×1620 mm; Ağırlık: 675kg.
Bdedjv Nl Sfspfx Al Iob
Lütfen yeni fiyatlarımızın genellikle kullanılmış ürün fiyatlarından daha düşük olduğunu aklınızda bulundurun. Paketleme görevinizi bize sorun ve anlatın. - Stoklarımızda genellikle 30-50 adet yeni makine hemen teslim edilebilmektedir. Ayrıca, müşteri spesifikasyonlarına göre üretilen makineler için yaklaşık 3 haftalık çok kısa teslimat sürelerimiz bulunmaktadır. - Tüm makinelerimiz tam garantilidir.
Küçük ilan
Wehr
2.400 km
Tablet presi
SPT Süd KoreaTP600
SPT Süd KoreaTP600
Çağrı
Koşul: yeni, Üretim yılı: 2026, toplam genişlik: 1.500 mm, toplam uzunluk: 2.500 mm, toplam yükseklik: 3.200 mm, Döner tablet presi SPT- TP600
2 vardiyalı üretim;
Dokunmatik ekran, PLC kontrol paneli;
HMI (İnsan Makine Arayüzü);
SPT-TP 600
İstasyon sayısı (maks.) 16 istasyon
1 Maks. tablet çıkarma 3000 - 18000 T/h
Bdedpsuac Sfjfx Al Ieb
2 Maks. tablet çapı yuvarlak mm 50
3 Maks. Tablet kalınlığı mm 15
4 Maks. Ana baskı kuvveti t 30
6 Boyutlar mm 1500 x 2500 x 3200
Küçük ilan
Gelsenkirchen
2.589 km
Tablet presi
HidrobrasilEinständerpresse
HidrobrasilEinständerpresse
Çağrı
Koşul: yeni gibi (kullanılmış), Üretim yılı: 2023, Fonksiyonellik: tamamen fonksiyonel, güç: 22 kW (29,91 bg), giriş voltajı: 400 V, giriş akımı: 32 A, giriş akımı türü: trifaze, presleme kuvveti: 20 t, toplam uzunluk: 2.400 mm, toplam genişlik: 1.500 mm, toplam yükseklik: 2.400 mm, toplam ağırlık: 2.000 kg, ortam sıcaklığı (min.): 10 °C, ortam sıcaklığı (maks.): 40 °C, kontrol paneli uzunluğu: 60 mm, kontrol kabini genişliği: 80 mm, yükseklik ayar tipi: hidrolik, Donanım: dokümantasyon / kılavuz, Hidrobrasil Tablet Press – 20 t – C-Frame – Manual Loading Press
For sale is a hydraulic single-column press (C-frame) from Hidrobrasil with a pressing force of 20 t, specifically designed for applications in the pharmaceutical and chemical industries. This machine is ideal for tablet production as well as precise pressing and forming processes for small series and laboratory applications.
=====
Technical Data & Information:
Bdjdpfetv Ewdox Al Iob
Hydraulic Tablet Press – 20 t
==== General Information
- Manufacturer: Hidrobrasil
- Model: Single-column Press
- Machine designation: Tablet Press
- Design: C-frame / Single-column
- Year of manufacture: 2023
- Location: Gelsenkirchen, Germany
- Pressing force: max. 20 t
- Machine weight: approx. 2 t
- Overall height: approx. 2,400 mm
==== Working Area
- Max. opening width: 500 mm
- Stroke / min. opening: 400 / 100 mm
- Table height above floor: 800 mm
==== Speeds
- Rapid close: 120 mm/sec
- Pressing speed: 5–10 mm/sec
==== Hydraulics & Drive
- Operating pressure: max. 250 bar
- Pressure accuracy: ±5 bar
- Main pump: Gear pump, approx. 10 l/min
- Oil volume: approx. 150 l (HLP 46)
- Main motor: 22 kW
- Total connected load: approx. 6 kW
==== Precision & Stability
- Parallelism deviation: ±0.1 mm at 20 °C
- Deflection: max. 0.3 mm/m
==== Control & Safety
- Control voltage: 24 V DC
- Light curtains: SICK / Pilz / Schmersal
- Two-hand operation, optional foot control
- Safety design according to EU standards and accident prevention regulations (UVV)
==== Features
- Table plate as tray with 50 mm edge and drain
- Position adjustment via sensors
- Pressure adjustment: 5–20 t via rotary control
- Control cabinet mounted on the right, protection class IP54
==== Operation & Performance
- Multi-tool: 8 press rams
- Output: approx. 8–12 parts per minute
- Hydraulic unit fully removable for maintenance
=====
Tablet production, pharmaceutical industry, chemical applications, laboratory presses, small batch production
Hydraulic press, tablet press, single-column press, C-frame press, pharmaceutical press, laboratory press
Looking for a hydraulic press tailored to your application? Contact us for a customized offer. Our hydraulic presses are manufactured in accordance with German machinery directives, as well as European machinery directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements as they fully comply with Brazil's national safety regulation NR 12, which is based on these standards. Our key strengths are custom machine construction and press automation. We supply tailored hydraulic presses at surprisingly attractive prices. For the hydraulics, we mainly use components from leading European manufacturers.
Küçük ilan
Denekamp
2.628 km
Tablet presi
Elizabeth HataECO III SL
Elizabeth HataECO III SL
Çağrı
Koşul: mükemmel (kullanılmış), Üretim yılı: 2016, Fonksiyonellik: tamamen fonksiyonel, Özel kalıpta 12 istasyonlu Slugger modeli
Maks. 120KN sıkıştırma kuvveti
100KN sıkıştırma kuvveti ile D takımında 16/20 istasyon mevcuttur
Bodorrgtrjpfx Al Iedb
GMP konstrüksiyonlu kare model.
İlaç dışı / ağır hizmet uygulamaları için isteğe bağlı elektromanyetik kavrama Ana motor için bir seçenek olarak ACVFD.
Slugging uygulaması için yüksek torklu motor.
Slugging/Effervesan tabletler/Veterinerlik/İlaç dışı uygulamalar için idealdir.
Sıkıştırma kuvveti izleme için yük hücresi opsiyonel olarak mevcuttur.
38 mm çaplı yuvarlak tablet kolaylıkla sıkıştırılır.
Küçük ilan
Gelsenkirchen
2.589 km
Vulkanizasyon presi
HidrobrasilLaborpresse
HidrobrasilLaborpresse
Çağrı
Üretim yılı: 2021, Koşul: yeni, presleme kuvveti: 50 t, Hidrobrasil Laboratory Press – 50 t – Vulcanizing Press – 200 × 200 mm – up to 250 °C
For sale is a hydraulic laboratory vulcanizing press from manufacturer Hidrobrasil with a pressing force of 50 t. This machine is specifically designed for thermal laboratory processes and enables precise control of pressure, position, and speed via state-of-the-art Siemens technology. Its compact design, integrated hydraulics, and monitored safety features make the press ideal for reproducible tests and small-batch production.
====
Technical Data & Information:
Hydraulic Laboratory Vulcanizing Press – 50 t
==== General Information
- Manufacturer: Hidrobrasil
- Model: Laboratory press
- Machine designation: Vulcanizing press
- Design: Bottom ram press
- Pressing force: 50 t
- Machine weight: approx. 1,500 kg
- Overall height: approx. 1,950 mm
==== Working Area
- Open height: 400 mm
- Stroke: 300 mm
- Heating platen size: 200 × 200 mm
==== Heating System
- Heating platen capacity: up to 250 °C
==== Hydraulics
- Hydraulics integrated within the press body
- Oil tank: 100 l
==== Control & Operation
- Control unit: Siemens S7-1200
- Touchscreen: Siemens, 9 inch
Bdjdpfx Alegrkigs Isb
- Adjustable: pressure, position, speed
==== Safety
- Safety technology: SICK
- Monitored vertical safety door for the pressing chamber
=====
Laboratory applications, vulcanization, hot pressing, materials testing, test series
Hydraulic press, hydraulic press, vulcanizing press, heating press, lab press, test stand press, industrial press
Looking for a hydraulic press tailored to your application? Contact us for a customized quote. Our hydraulic presses are manufactured according to German and European Machinery Directives (Directive 2006/42/EC), as well as EC standards and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements, as they comply with all aspects of the national Brazilian safety directive NR 12, which builds on these standards. Our core strength lies in custom machine building and press automation. We supply tailor-made hydraulic presses at surprisingly competitive prices. For the hydraulics in our presses, we mainly use components from leading European manufacturers.
Küçük ilan
Ennepetal
2.563 km
Dört sütunlu pres
HidralmacLaborpresse
HidralmacLaborpresse
Çağrı
Koşul: ikinci el, presleme kuvveti: 30 t, makine/araç numarası: DF0139, Hidralmac Four-Column Laboratory Press – 30 t – 1,000 × 1,000 mm – High-Speed
For sale is a hydraulic four-column laboratory press from Hidralmac with a pressing force of 30 t. This machine is ideally suited for laboratory applications, testing operations, and small series production where high travel speeds and precise pressure control are required.
====
Technical Data + Information:
Hydraulic Four-Column Press – 30 t
==== General Information
- Manufacturer: Hidralmac
- Model: Laboratory Press
- Machine designation: Four-column press
- Design: Four-column press
- Pressing force: 30 t
Bdedsfxykhspfx Al Ijb
- Machine weight: approx. 5 t
- Total power requirement: 3 kW
- Space requirement (L × W × H): approx. 3,360 × 1,300 × 1,360 mm
==== Working Area
- Passage width: 1,000 × 1,000 mm
- Max. distance table – ram: 1,000 mm
- Stroke: 800 mm
- Table height above floor: approx. 900 mm
==== Table & Ram
- Column diameter: 75 mm
- Cylinder diameter: 126 mm
- Piston diameter: 71 mm
- Return force: 3 t
==== Speeds
- Approach speed: up to 200 mm/sec
- Working speed: 0–10 mm/sec
- Return speed: 200 mm/sec
==== Applications & Features
- High travel speeds for efficient processes
- Precise pressure control in low-force applications
- Compact design for laboratory and testing environments
- Suitable for test setups and small batch production
=====
Laboratory applications, test engineering, small batch production, material testing, research
Hydraulic press, laboratory press, four-column press, testing press, industrial press, trial press
Are you looking for a hydraulic press tailored to your application? Contact us for an individual offer. Our hydraulic presses are built to comply with German Machinery Directive as well as the European Machinery Directive (Directive 2006/42/EC), EC standards, and EU safety regulations. Additionally, our presses exceed both Canadian and European safety requirements as they fully comply with the Brazilian national safety standard NR 12, which incorporates and surpasses these standards. Our core strengths are special machine construction and press automation. We deliver tailor-made hydraulic presses at surprisingly competitive prices. The hydraulics of our presses are fitted predominantly with components from leading European manufacturers.
Küçük ilan
Ennepetal
2.563 km
ısıtma presi
HidrobrasilVulkanisierpresse
HidrobrasilVulkanisierpresse
Çağrı
Koşul: yeni, Üretim yılı: 2019, makine/araç numarası: DF0277-Rev06, presleme kuvveti: 10 t, Hidrobrasil Vulcanizing Press – 10 t – Heating Press – 660 × 210 mm – with Heated Plates
Bjdpfsffamyjx Al Iedb
For sale is a hydraulic vulcanizing press from Hidrobrasil with 10 t pressing force. The machine is designed for thermal processes such as vulcanization and hot pressing applications, featuring precisely guided heated plates and the ability to maintain constant pressure over extended periods. Thanks to safety monitoring and robust construction, this press is ideally suited for reliable use in both laboratory and production environments.
====
Technical Specifications & Information:
Hydraulic Vulcanizing Press – 10 t
==== General Information
- Manufacturer: Hidrobrasil
- Model: Vulcanizing Press
- Machine type: Heating Press
- Design: Single-column/column press
- Pressing force: 10 t
- Machine weight: approx. 1.5 t
- Dimensions (L × W × H): approx. 2,000 × 1,420 × 760 mm
==== Working Area
- Column gap: 200 mm
- Open height between heating plates: 200 mm
- Stroke: 200 mm
- Travel distance: 200 mm
==== Heating Plates & Build
- Heating plates: 660 × 210 mm
- Table height: 1,100 mm
- Table plate thickness: 125 mm
- Ram height: 250 mm
- Plates ground flat (incl. thermal insulation plates and clamping surfaces)
==== Construction & Guides
- Chrome-plated, polished guide columns
- Parallel guidance via 250 mm high bronze guides
- Counterweight system for easy door operation
==== Process Parameters
- Pressure constancy: up to 5 hours
- Pressure tolerance: max. ± 5%
==== Hydraulics
- Oil tank: 70 l
==== Safety & Operation
- Electronic door monitoring
- Locking: Ram movement only with closed door
- Opening protection at >50°C plate temperature
- Manual override with safety release ("Burn hazard" warning)
=====
Vulcanization, hot pressing, thermal processes, laboratory applications, material testing
Hydraulic press, vulcanizing press, heating press, laboratory press, production press, industrial press
Looking for a hydraulic press tailored to your specific application? Contact us for a customized offer. Our hydraulic presses are manufactured in compliance with German machinery guidelines, as well as European Machinery Directive (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements, as they fully comply with the national Brazilian safety standard NR 12, which is based on these standards. Our key strength lies in custom machine construction and press automation. We offer tailor-made hydraulic presses at surprisingly affordable prices. For the hydraulics, we mainly use components from leading European manufacturers.
Küçük ilan
Ennepetal
2.563 km
Tuz presi
HidralmacMineralsteinpresse
HidralmacMineralsteinpresse
Çağrı
Üretim yılı: 2020, Koşul: yenilenmiş (kullanılmış), presleme kuvveti: 400 t, makine/araç numarası: DF0317, Hidralmac Mineral Block Press – 400 t – Salt Press – 600 mm Clearance – with Conveyor Belt
For sale is a hydraulic mineral block press from Hidralmac with a pressing force of 400 t. The machine is specially designed for the production of salt and mineral block products and features an integrated conveyor belt for efficient material flow. Thanks to its robust construction and stainless steel components in product-contact areas, the press is ideal for continuous industrial operation.
====
Technical specifications & information:
Hydraulic Mineral Block Press – 400 t
==== General information
- Manufacturer: Hidralmac
- Model: Mineral Block Press
- Machine designation: Salt Press
- Design: Four-column press
- Pressing force: 400 t
- Machine weight: approx. 14 t
- Dimensions (L × W × H): 2,380 × 1,680 × 3,580 mm
- Motor power: 36 kW
==== Work area
- Clearance width: 600 mm
- Max. working height: 750 mm
- Stroke: 400 mm
- Ram travel: 500 mm
==== Table & construction
- Column diameter: 230 mm
- Return force: 40 t
- Steel grade: Structural steel LCG ASTM A36 (DIN 8651)
- Product-contact parts: stainless steel
==== Speeds
- Approach speed: max. 10 mm/sec
- Pressing speed: 10 mm/sec
- Rapid traverse: 25 mm/sec
==== Hydraulics & peripherals
- Oil tank: 600 l
Bsdpfed E Irhjx Al Iedb
- Oil cooling: 1.5 kW
- Conveyor belt: 6 m length
==== Control
- Monitor: WEG, 12 inch
=====
Salt pressing, mineral block production, pressing processes, industrial manufacturing
Hydraulic press, hydraulic press, mineral block press, salt press, production press, industrial press, forming press
Looking for a hydraulic press tailored to your application? Contact us for an individual offer. Our hydraulic presses are manufactured according to German machinery regulations as well as European machinery directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements, as they comply fully with the Brazilian national safety guideline NR 12, which is based on these standards. Our core strength lies in special-purpose machine construction and press automation. We offer custom-built hydraulic presses at surprisingly low prices. For the hydraulics, we mainly use components from leading European manufacturers.
Küçük ilan
Wehr
2.400 km
Döndürme tablet basın
SPT Süd KoreaTP500D
SPT Süd KoreaTP500D
Çağrı
Üretim yılı: 2026, Koşul: yeni, Döner Tablet tuşuna basın SPT - TP 500 D ile 2 kat üretim ile çift taraflı basın.
Çift taraflı basın;
2 katman üretim;
GMP düzenlemelere göre;
Dokunmatik ekran, PLC kontrol plarform;
HMI sistemi;
SPT-TP 500D
Durağı (maks.) D = 41 B = 49 BB 59 =
1 Max.Tablet (iki taraflı) Çıkış sekmesi/h 270 000 360 000 420 000
2 katman sekmesi/h 90 000 115 000 140 000 Max.Tablet çıkış
2 Max.Tablet çapı Yuvarlak mm 13 16 25
Şekilli 14 19 25
Bodpfxsdy Dz Aj Al Ijdb
3 Max. Kalınlık mm 8,5 4 tablet Max. Ana sıkıştırma zorlamak Ton 10 6 Makine Boyut mm 1150 x 1550 x 1950
Küçük ilan
Wehr
2.400 km
Döner tablet basın
SPTTP-400
SPTTP-400
Çağrı
Üretim yılı: 2026, Koşul: yeni, Döner Tablet basın SPT-TP 400 yüksek hızlı üretim kapasitesi ile.
Yüksek hızlı üretim kapasitesi;
GMP düzenlemelere göre;
Dokunmatik ekran, PLC kontrol platformu;
HMI sistemi;
SPT-TP 400
Durağı (maks.) D = 30 B = 36 BB = 45
Sekme/h 125000 170 000 215 000 1 Max.Tablet çıkış
2 Max.Tablet çapı Yuvarlak mm 13 16 25
Şekilli mm 14 19 25
3 Max. Kalınlık mm 8,5 4 tablet Max. Ana sıkıştırma zorla Ton 10 5 Max. Ön sıkıştırma zorlamak Ton 2 6 Makine Boyut mm 1000 x 1230 x 2000
Bedsdy Dzropfx Al Isdb
Küçük ilan
Wehr
2.400 km
Döner tablett basın
SPTTPL -200
SPTTPL -200
Çağrı
Üretim yılı: 2026, Koşul: yeni, Döner tablet basın SPT-TPL200 küçük rotary basın R&D ve küçük ölçekli üretim yapıyor.
GMP düzenlemelere göre;
Dokunmatik ekran, PLC kontrol platformu;
HMI sistemi;
Bsdpfxody Dzij Al Iedb
Açıklama SPT-TPL 200
Durağı (maks.) D = 13 B = 16 BB = 19
Sekme/h 46 000 57 000 68 000 1 Max.Tablet çıkış
2 Max.Tablet çapı Yuvarlak mm 25 16 13
Şekilli mm 25 19 14
3 Max. Kalınlık mm 8,5 4 tablet Max. Ana sıkıştırma zorla Ton 5 5 Max. Ön sıkıştırma zorlamak Ton 1 6 Makine Boyut mm 600 x 1106 x 1705
Küçük ilan
Brezilya
10.769 km
Tuz presi
HidrobrasilMineralsteinpresse
HidrobrasilMineralsteinpresse
Çağrı
Koşul: yeni, Üretim yılı: 2020, presleme kuvveti: 300 t, makine/araç numarası: DF0240 - Rev.00, Hidrobrasil Salt Press – 300 t – 600 × 600 mm – Mineral Block Press
For sale is a hydraulic mineral block or salt press from Hidrobrasil with a pressing force of 300 t. This machine is specifically designed for the production of salt blocks and comparable pressed products. It allows for efficient series production thanks to its integrated ejector and optional automation.
=====
Technical Data & Information:
Hydraulic Salt Press – 300 t
==== General Information
- Manufacturer: Hidrobrasil
- Model: Mineral Block Press
- Machine designation: Salt Press
- Type: Hydraulic Production Press
- Pressing force: 300 t
- Machine weight: approx. 8.5 t
- Dimensions (L × W × H): approx. 2,275 × 1,650 × 4,050 mm
- Motor power: 30 kW
==== Working Area
- Pass-through width: 600 mm
- Max. working height: 800 mm
- Stroke: 500 mm
==== Table & Ram
- Table size: 600 × 600 mm
- Ram plate: 600 × 600 mm
- Table height above floor: 850 mm
- Retraction force: 30 t
==== Speeds
- Advance speed: max. 10 mm/sec
- Pressing speed: 10 mm/sec
==== Hydraulics & Features
- Oil tank: 350 l
- Electric oil cooling: 1.5 kW (max)
- Travel distance: 500 mm
==== Ejector
- Ejector stroke: 250 mm
- Ejector force: 50 t
==== Options (on request)
- Perimeter maintenance platform
- Oil drip pan
- Upper and lower tooling for salt blocks (e.g. 8 kg)
- Automatic filling with 500 kg batch hopper
- Speed increase up to 80 mm/sec
- Conveyor belt extensions
- Light barriers at the front and rear
- Side panels
- Roller conveyor system for transport and intermediate storage
Bdedodxvfkspfx Al Ijb
=====
Salt production, mineral block manufacturing, series production, pressed parts, chemical applications
Hydraulic press, salt press, mineral block press, production press, industrial press, pressing system
Are you looking for a hydraulic press tailored to your application? Contact us for a custom quotation. Our hydraulic presses are manufactured according to German machinery directives as well as European machine directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed both Canadian and European safety standards, as they are fully compliant with the national Brazilian safety directive NR 12, which is based on these standards. Our core competency is special-purpose machine construction and press automation. We supply customized hydraulic presses at surprisingly affordable prices. For the hydraulics, we primarily use components from leading European manufacturers.
Küçük ilan
Ennepetal
2.563 km
Tuz presi
HidralmacMineralsteinpresse
HidralmacMineralsteinpresse
Çağrı
Üretim yılı: 2020, Koşul: yeni gibi (kullanılmış), presleme kuvveti: 150 t, Hidralmac Salt Press – 150 t – Mineral Lick Press – Stainless Steel Contact Surfaces
For sale is a hydraulic mineral lick or salt press manufactured by Hidralmac with a pressing force of 150 t. This machine is specifically designed for the production of salt and mineral blocks and features stainless steel contact surfaces for hygienic and corrosion-resistant operation. Thanks to its robust construction and optional add-ons, it is suitable for continuous industrial operation.
====
Technical Data & Information:
Hydraulic Salt Press – 150 t
==== General Information
- Manufacturer: Hidralmac
- Model: Mineral Lick Press
- Machine type: Salt Press
- Design: Hydraulic Production Press
- Pressing force: 150 t
- Machine weight: approx. 8.5 t
- Dimensions (L × W × H): 1,200 × 1,800 × 3,100 mm
- Motor power: 10 kW
- Steel specification: Structural Steel LCG ASTM A36
==== Working Area
- Max. working height: 1,000 mm
- Stroke: 500 mm
- Table height above floor: 1,000 mm
==== Speeds
- Approach speed: max. 9.9 mm/sec
- Pressing speed: up to 100 t: 9.9–0 mm/sec
- Return speed: 25 mm/sec
==== Hydraulics & Technology
- Hydraulic tank: 500 l
- Oil capacity: approx. 400 l
- Column diameter: 230 mm, chrome-plated
- Lubrication: manual via grease nipples
==== Construction & Features
- All product-contact parts made of stainless steel
- Robust design for salt and mineral processing
- High corrosion resistance
- Maintenance-friendly construction
==== Options (on request)
- Surrounding maintenance balcony
- Enclosed side covers (left/right/rear)
- Front light curtains (extended speed)
- Increased speed
- Siemens S7-1200 control system with 12" display
- Pilz safety technology
Bedpfx Aledxvfie Iodb
=====
Salt production, mineral block manufacturing, chemical industry, compacts, serial production
Hydraulic press, salt press, mineral lick press, production press, industrial press, press line
Are you looking for a hydraulic press tailored to your specific application? Contact us for a customized offer. Our hydraulic presses are manufactured according to German Machinery Directives, as well as European Machinery Directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety standards as they fully comply with the Brazilian national safety regulation NR 12, which builds on these standards. Our main strength lies in special-purpose machine construction and press automation. We offer bespoke hydraulic presses at surprisingly affordable prices. For the hydraulic systems, we primarily use components from leading European manufacturers.
