Sütunlu delme makinesi, sütunlu delme makinesiGILLARDON
GSB 32 V
Sütunlu delme makinesi, sütunlu delme makinesi
GILLARDON
GSB 32 V
sabit fiyat KDV hariç
€3.500
Durumu
Kullanılmış
Konum
Hessisch Lichtenau

Resimleri göster
Haritayı göster
Makineye ait bilgiler
- Makine tanımı:
- Sütunlu delme makinesi, sütunlu delme makinesi
- Makine üreticisi:
- GILLARDON
- Model:
- GSB 32 V
- Durumu:
- kullanılmış
Fiyat ve Konum
sabit fiyat KDV hariç
€3.500
- Konum:
- 37235 Hessisch Lichtenau

Ara
Teklif detayları
- Listeleme kimliği:
- A21173077
- Referans no.:
- 62323
- Son güncelleme tarihi:
- 05.02.2026
Açıklama
Column Drilling Machine Gillardon Type GSB 32 V
Machine No.: Year of manufacture approx. 1975
Drilling capacity: 32 mm
Taper: MK 4 - long quill
Throat: 350 mm
Quill stroke: 170 mm
Table size: 570 x 470 mm
Column diameter: 140 mm
Spindle speed at motor speed stage 1, belt stage 1: 50 - 300 rpm, stepless
Ksdpfoyhf Izox Ag Sowu
Spindle speed at motor speed stage 2, belt stage 1: 100 - 600 rpm, stepless
Spindle speed at motor speed stage 1, belt stage 2: 100 - 500 rpm, stepless
Spindle speed at motor speed stage 2, belt stage 2: 150 - 1000 rpm, stepless
Motor power: 1 / 1.5 kW
Power connection: 380 Volt, 50 Hz
- Automatic feed approx. 0.1 / 0.16 / 0.25 mm/rev, 3 stages
- Spindle speed via 2 motor speeds, 2 V-belt stages and variator gearbox
- Adjustable drilling depth stop
- Table height adjustment via rack and pinion with hand crank
- Drill table tiltable with degree scale
- Drill chuck RÖHM Ø 1 to 13 mm
- Machine lamp
Required space L x W x H: 1000 x 750 x 2000 mm
Weight: 470 kg
Good condition
Bu ilan otomatik olarak tercüme edildiğinden bazı çeviri hataları oluşmuş olabilir.
Machine No.: Year of manufacture approx. 1975
Drilling capacity: 32 mm
Taper: MK 4 - long quill
Throat: 350 mm
Quill stroke: 170 mm
Table size: 570 x 470 mm
Column diameter: 140 mm
Spindle speed at motor speed stage 1, belt stage 1: 50 - 300 rpm, stepless
Ksdpfoyhf Izox Ag Sowu
Spindle speed at motor speed stage 2, belt stage 1: 100 - 600 rpm, stepless
Spindle speed at motor speed stage 1, belt stage 2: 100 - 500 rpm, stepless
Spindle speed at motor speed stage 2, belt stage 2: 150 - 1000 rpm, stepless
Motor power: 1 / 1.5 kW
Power connection: 380 Volt, 50 Hz
- Automatic feed approx. 0.1 / 0.16 / 0.25 mm/rev, 3 stages
- Spindle speed via 2 motor speeds, 2 V-belt stages and variator gearbox
- Adjustable drilling depth stop
- Table height adjustment via rack and pinion with hand crank
- Drill table tiltable with degree scale
- Drill chuck RÖHM Ø 1 to 13 mm
- Machine lamp
Required space L x W x H: 1000 x 750 x 2000 mm
Weight: 470 kg
Good condition
Bu ilan otomatik olarak tercüme edildiğinden bazı çeviri hataları oluşmuş olabilir.
