Enjeksiyon kalıplama makinesi

KraussMaffei KM 120-380 EX aus Reinraumfertigung

Here we offer, as a dealer for injection moulding machines, the following well-maintained used injection moulding machine:

Of course, we also purchase well-maintained injection moulding machines from model year 2010 onwards.
We have been wholesalers of injection moulding machines for over 25 years.

++++From pharmaceutical cleanroom production++++

Manufacturer: KraussMaffei
Machine type: KM 120-380 EX

International designation: 380 EX / 120
Machine no.: 61011287
Year of manufacture: 2008
Operating hours: 61,300 h
Control system: MC5

Technical Data – Clamping Unit
Clamping force: 1,200 kN
Tie bar spacing (H x V): 470 x 470 mm
Platen size (H x V): 780 x 735 mm
Min. mould height: 200 mm
Max. mould height: 450 mm
Max. platen daylight: 850 mm
Opening stroke: 400 mm
Ejector stroke: 150 mm
Ejector force: 22 kN
Movable platen centering diameter: 160 mm
Fixed platen centering diameter: 125 mm
Max. mould weight: 1,485 kg

Technical Data – Injection Unit
Screw diameter: 35 mm
Shot volume: 156 cc
Injection pressure: 2,429 bar
Screw length: 23 L/D
Screw speed: 289 rpm
Plasticizing rate: 27 g/s PS
Free injection rate: 477 g/s PS
Number of heating zones: 5

Dimensions & Weight
Machine dimensions (L x W x H): 6 m x 1.7 m x 2.19 m
Total weight: 9,700 kg

Equipment
Screen language: German
Screen language: English

+++Extras+++
Automation: Handling device / removal robot included – Handling: LR 100-2300
Conveying technology: roller conveyor included
CE marking: available
Full maintenance and acceptance history
Complete last test report
Dedpfx Alsy D Adtj Toch
Incl. conveyor belt incl. safety cage
Machine with water battery
Machine without material hopper
Levelling elements
EUROMAP 12 interface

Electrics
Schuko socket 10A
CEE socket 16A
Voltage: 400 V
Frequency: 50 Hz
Motor current: 80 A

Warranty
Warranty up to initial commissioning

Loading / Shipping
Free loading onto buyer’s truck or free delivery (ex-works, freight at cost)
Available from our warehouse in Hanover, Germany.

Bu ilan otomatik olarak tercüme edildiğinden bazı çeviri hataları oluşmuş olabilir.
