Dört taraflı planya makinesi

Kupfermühle 70

CATALOG NUMBER 7965

TECHNICAL DATA
- Max planing width: 770 mm
- Max dual-side planing height: 200 mm
- Electric table height adjustment (up/down)
- Max four-side planing height: 120 mm

Top unit:
- Feed roller, toothed
- Kickback fingers
- Pressure roller
- Toothed feed roller
- Pressure roller
- Planing shaft 770 mm, 4-knives, 7.5 kW
- Pressure roller
Pgedpjzab Afofx Al Iol
- Smooth outfeed roller

Bottom unit:
- Guide bar
- Smooth feed roller
- Planing shaft 770 mm, 4-knives, 5.5 kW
- 2 smooth feed rollers

Rear unit:
- 2 side spindles with pressure rollers
1) Right vertical, 120 mm, 4 kW
2) Left vertical, 120 mm, 4 kW
- Spindle diameter: 35 mm
- Spindles adjustable up/down and left/right
- Manual planing width adjustment
- 4 feed speeds: 6/9/12/18 m/min
- Feed motor: 3.0 kW
- Extraction outlet diameters: 130 mm, 180 mm, 2 x 120 mm
- Dimensions (L x W x H): 2200 x 1750 x 1630 mm
- Weight: approx. 3000 kg

ADVANTAGES
- Ideal for processing beams, flooring, etc.
- Manufactured by German brand KUPFERMUHLE
- Complete with 2 side cutter heads
- 2 horizontal planing shafts + 2 vertical spindles
- Used planer, in very good condition

Net price: 45,900 PLN
Net price: 10,929 EUR (based on 4.20 EUR exchange rate)
(Prices may change with significant fluctuations)
