çift kolonlu portal işleme freze makinesi
UNISIGN Uniport 6000

Name: UNISIGN Uniport 6000
Brand: UNISIGN
Availability: InStock

Üretim yılı

2007

Durumu

Kullanılmış

Konum

Almanya

çift kolonlu portal işleme freze makinesi UNISIGN Uniport 6000

Haritayı göster

Makineye ait bilgiler

Makine tanımı:: çift kolonlu portal işleme freze makinesi

Makine üreticisi:: UNISIGN

Model:: Uniport 6000

Üretim yılı:: 2007

Durumu:: kullanılmış

Fiyat ve Konum

Konum:: Deutschland

Ara

Teklif detayları

Listeleme kimliği:: A21414647

Referans no.:: 1077-04053

Son güncelleme tarihi:: 04.03.2026

Açıklama

x-axis travel: 3000 mm
y-axis travel: 2500 mm
z-axis travel: 1000 mm
Control: Siemens
Type: Sinumerik 840 D
Feed rate: 5–30,000 mm/min
Table size: 2000 x 2170 mm
Blodpfx Ageyqu D Domed
Table load: 1500 kg/m²
T-slots: 22 H9
Column passage: 2500 mm
Spindle speed: 6000 rpm
Spindle motor: 36 kW
Spindle taper: HSK 100
Tool changer: 30 positions
Rotary table: 2000 mm
Table speed: 250 rpm
Turning diameter: 2500 mm
Table load: 10 t
Torque: 33,000 Nm
Machine weight: approx. 45 t
Dimensions: approx. 8 x 6.4 x 4.4 m
Gantry portal milling machine with carousel rotary table
Head change station
Tool changer

Technical data provided by manufacturer or operator and therefore not binding for us. Subject to prior sale; solely our terms and conditions of business and sale apply.

About us
- More than 400 machines in stock
- Over 15,000 m² warehouse space, crane capacity 70 t
- Over 10,000 accessory items for your workshop

If you wish to sell machinery, production lines, or your business, please contact us.

Further offers can be found on our website.
Viewings are possible by appointment.

We look forward to your visit.
Your Markus Hirsch Team

Bu ilan otomatik olarak tercüme edildiğinden bazı çeviri hataları oluşmuş olabilir.
