İkinci El Preform Satın Al (56)

Durum: yeni, We manufacture these AVS25, AVS40, AVS63 & AVS100 heading machines completely new. The AVS four-hammer heading machine series provides reliable and precise pre-forming for tubes and bars, preparing them for drawing. Whether hot or cold forming, AVS machines guarantee symmetrical results, minimal waste, and an excellent surface finish. Their robust design ensures stable and efficient operation for all your metal heading needs. New Heading Machine: AVS63 Suitable for: Cold and hot heading Feed: Automatic and manual Forming force (hammer force): 4 x 63 Mp Number of strokes: 630/min Starting diameter for round ends: 15 - 115 mm Starting diameter for flattened ends: 28 - 150 mm Tip diameter for both types: Max. 75 mm Infinitely adjustable feed rate: 0 - 100 mm/sec Hjdpfx Anoymadnjyefn

Durum: yeni, We manufacture these AVS25, AVS40, AVS63 & AVS100 pointer machines completely new. The AVS four-hammer heading machine series provides reliable and precise preforming for tubes and bars, preparing them for drawing operations. Whether hot or cold forming, the AVS machines ensure symmetrical results, minimal waste, and an excellent surface finish. Their robust design guarantees stable and efficient operation for all your metal heading requirements. New pointer machine: AVS25 Suitable for: Cold and hot heading Feeding: Automatic and manual Hedpfx Anoymaduoyefn Forming force (hammer force): 4 x 25 Mp Number of strokes: 800/min Starting diameter for round ends: 10 - 75 mm Starting diameter for folded ends: 18 - 100 mm Maximum tip diameter for both cases: 50 mm Feed rate, steplessly adjustable: 0 - 70 mm/sec

Durum: ikinci el, Üretim yılı: 2004, Genel Bakış Bu streç şişirme makinesi, 2004 yılında Alman firması KRONES tarafından üretilmiştir. CONTIFORM S8 modelidir; PET şişe üretimi için tasarlanmış olup, PCO 1881 ve Alaska şişe ağız tipleri için konfigüre edilmiştir. Şişirme makinesi hemen teslim edilebilir durumdadır. Teknik Bilgiler - Kapasite: - Maks. 13.600 şişe/saat - Formatlar: - 0,50 l - 1,00 l - 1,50 l - Ağız tipi: - PCO 1881 - Alaska - Kavitasyon sayısı: Hfodpfeylacuex Anysn - 8 kalıp - Çalışma saati: - yaklaşık 35.000 saat Teslimat Kapsamı - KRONES CONTIFORM S8 Streç Şişirme Makinesi - Preform haznesi ve besleme - Soğutucu - 6 kalıp seti - Yedek parçalar

Durum: yeni, We manufacture these AVS25, AVS40, AVS63 & AVS100 heading machines completely new. Hfjdpfeymadhex Anyen The four-hammer AVS heading machine series offers reliable and precise preforming for tubes and bars, preparing them for drawing processes. Whether working with hot or cold forming, the AVS machines ensure symmetrical results, minimal waste, and an excellent surface finish. Their robust design guarantees stable and efficient operation for all your metal heading requirements. New heading machine: AVS40 Suitable for: Cold and hot heading Feeding: Automatic and manual Forming force (hammer force): 4 x 40 Number of strokes: 710/min Starting diameter for round points: 12 - 90 mm Starting diameter for folded points: 20 - 120 mm Maximum tip diameter for both types: max. 60 mm Infinitely variable feed rate: 0 - 100 mm/sec

Durum: işlem için hazır (kullanılmış), Üretim yılı: 2000, Fonksiyonellik: tamamen fonksiyonel, toplam ağırlık: 8.700 kg, iş parçası uzunluğu (maks.): 165 mm, iş parçası çapı (maks.): 35 mm, üretim kapasitesi: 7.200 birim/s, TECHNICAL DETAILS Number of cavities: 6 Maximum output: 7,200 bottles/hour Product dimensions Maximum preform length: 165 mm Preform diameter: 18–35 mm Neck ring diameter: 27–42 mm Maximum neck-finish diameter: 38 mm Neck height: 9–27 mm Maximum bottle height: 350 mm Maximum bottle diameter: 105 mm Maximum bottle volume: 2 L MACHINE DETAILS Hodpfx Anoyrfvgeysfn Dimensions & Weight Blow molding module (L × W × H): 3,293 × 2,325 × 3,196 mm Control cabinet (L × W × H): 1,998 × 602 × 2,410 mm Blow molding module weight: 6,300 kg Control cabinet weight: 1,200 kg Preform feeder: 1,200 kg Total weight: 8,700 kg Noise level: 83 dB(A) Installed power Installed power: max. 160 kW Typical consumption (1,500 ml bottle): 88 kW Typical consumption (1,000 ml bottle): 62 kW Typical consumption (500 ml bottle): 45 kW Infrared heater (9 zones): 132 kW Operation and feeding system: 28 kW Power supply Supply voltage: 230/400 V ±10 % Frequency: 50 Hz ±1 % Cooling water Cooling capacity: 20,000 kcal/h Water temperature: 8–12 °C Flow rate: max. 5 m³/h Pressure: 3–5 bar Compressed air Air consumption at 40 bar (0.25–2 L bottle): 180–700 Nm³/h Air consumption at 7 bar (operating air): 35 Nm³/h

Durum: işlem için hazır (kullanılmış), Üretim yılı: 1993, Fonksiyonellik: tamamen fonksiyonel, ürün yüksekliği (maks.): 380 mm, iş parçası çapı (maks.): 130 mm, üretim kapasitesi: 7.200 birim/s, TECHNICAL DETAILS Number of cavities: 6 Capacity with standard bottles: up to 7,200 bph Product formats Bottle volume: 0.25 - 3.0 L Max. bottle height: 380 mm Max. bottle diameter: 130 mm Preform dimensions Max. preform length: 210 mm Neck inner diameter: 34 mm Hfsdpsx A Uu Ejfx Anyon MACHINE DETAILS Dimensions & Weight Blow module dimensions: 2,000 x 2,200 x 2,200 mm Blow module weight: 8,000 kg Oven dimensions: 3,000 x 1,100 x 2,100 mm Oven weight: 2,000 kg Control cabinet dimensions: 1,500 x 1,000 x 2,100 mm Control cabinet weight: 1,000 kg Transformer 415V / 380V dimensions: 1,000 x 500 x 2,000 mm Transformer weight: 500 kg Preform hopper and conveyor dimensions: 3,000 x 1,500 x 3,500 mm Preform hopper and conveyor weight: 600 kg Preform infeed dimensions: 2,000 x 2,500 mm Preform infeed weight: 250 kg Feeding guide rails length: 2,000 mm Power supply Total power: 142 kW Power connection: 380/420 V +/- 10%, 50 Hz +/- 1% Cooling water Cooling capacity: 16,000 kcal/h Water temperature: 10 - 12 °C Flow rate: up to 6.0 m³/h Water pressure: 5 - 6 bar Compressed air Service air pressure: 7 bar Service air flow: 50 - 100 Nm³/h Blowing air pressure: up to 35 bar Blowing air flow for 0.25 - 3.0 L: 155 - 770 Nm³/h EQUIPMENT Transformer 415V / 380V Preform hopper and conveyor Preform infeed Feeding guide rails Adaptation to other voltage upon request
